Description
| คุณสมบัติ | Value |
| Coil Voltage | 24 V dc |
| Number of Poles | 3 |
| Contact Current Rating | 60 A |
| Normal State Configuration | 5NO/2NC |
| Contact Voltage Rating | 525 V ac |
| Series | 100S-C |
| Number Of Auxiliary Contacts | 4 |
| Function | Safety |
| Auxiliary Contact Configuration | 2NO + 2NC |
| Terminal Type | Screw |
| Width | 72mm |
| Depth | 156mm |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -25°C |
| Length | 122mm |
Allen Bradley Safety Contactor
The Allen Bradley 100S-C series safety contactor has a 3-pole and current rating of 60A. It has 2NO and 2NC contact configuration. The coil voltage rating is 24VDC. This contactor has mechanically linked positively guided contacts, required in feedback circuits of modern safety applications. The mechanically linked N. C. auxiliary contacts do not change their state when a power pole welds. The gold: plated bifurcated auxiliary contacts are ideal for low: energy applications. This device is ideal for feedback control circuits with multiple series: connected N. C. auxiliary contacts.
Note:
DC versions incorporate a diode protection circuit.
Features and Benefits
Redundant contactors to isolate motor (hazardous motion)
Positively guided main contacts
Red contact housings for easy identification as safety device
Protective cover prevents manual operation , yet the window allows visible on/off status
Contact voltage rating 525VAC
Certifications
CE certified
UL listed
CSA certified
RINA certified
IEC60947
EN60947
