Description
| คุณสมบัติ | Value |
| Number of Poles | 6 |
| Maximum Current | 40A |
| IP Rating | IP66 |
| Power Rating | 18.5kW |
| Voltage Rating | 690V ac |
| Accepts Padlocks | Yes |
| Handle Colour | Black/Grey, Red/Yellow |
| Switch Rating | 20kA |
| Length | 230mm |
| Width | 175mm |
| Depth | 120mm |
| Terminal Type | Wire Lead |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -25°C |
Enclosed Switch Disconnectors
ABS thermoplastic enclosures
Cover interlocked to prevent removal when live
Handle can be padlocked in up to three positions in the OFF position
Earth connection in base of enclosure
Standards: IEC 947, VDE 0660
Approvals: UL, CSA
Standards
IEC 947, VDE 0660
Approvals
UL, CSA
Allen Bradley MCS Range
The 194E switch disconnector range forms part of the Modular Control System (MCS) 9mm grid system and similarly features compact design, modularity and extensive choice, all switch materials can be recycled. Universal terminal screws are fitted for ’Pozidriv’ or flat blade screwdriver. The switching category is AC23A.
