Description
| คุณสมบัติ | Value |
| Number of Poles | 1P+N |
| Current Rating | 2A |
| Tripping Characteristics | Type C |
| Rated AC Voltage | 230V |
| Range | Acti 9 |
| Model Number | IDT40T |
| Series | Acti9iDT40T |
| Breaking Capacity at Maximum Voltage Rating | 6 kA |
| Circuit Breaker Type | MCB |
| Mounting Style | DIN Rail Mount |
| Width | 74mm |
| Length | 18mm |
| Depth | 85mm |
| Terminal Contact Type | Screw |
| Tripping Mechanism | Thermal-Magnetic |
| Reset Actuator Type | Toggle Switch |
Schneider Electric Miniature Circuit Breaker, Type C, 6kA Breaking Capacity – iDT40T Series – A9P22602
Provide vital protection against short circuits and overload currents with this miniature circuit breaker (MCB) from Schneider Electric. Its Type C curve, which trips at a rate of five to ten times the 2A rated current, makes it suited to high-inductive loads with high switching surges. It also safeguards users against indirect contact with TN (transformer neutral) and IT (unearthed transformer neutral) systems by cutting power when there’s a fault between the live part and an exposed conductive point.
Features & Benefits
• Robust screw connections offer twice the normal tightening torque, making the unit highly durable
• Easy to install on a DIN rail with a double clip
• Compact size of 18 (L) x 74 (W) x 85mm (D) allows for use in busy setups
Applications
• Manufacturing equipment
• Domestic lighting circuits
• Building industry
What’s meant by a current rating?
The current rating refers to the maximum current that can pass through a device before it will trip. This product has a current rating of 2A.
What does 1P+N mean?
1P+N stands for one pole plus neutral. This means the live and neutral wires can be turned off and on at the same time.
