Description
| คุณสมบัติ | Value |
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | Flange Mount |
| Switching Current | 30A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Quick Connect |
| Coil Resistance | 300Ω |
| Coil Power | 3.4W |
| Maximum Switching Voltage AC | 600V |
| Length | 38.89mm |
| Height | 35.72mm |
| Standards Met | CSA, UL |
| Depth | 48.42mm |
| Isolation Coil To Contact | 2.5kV ac |
| Maximum Switching Power AC | 3.4 VA |
| Application | Power |
Schneider Electric Non-Latching Relay, 2 Poles, 30A Switching Current – 300 Series – 300XBXC1-24D
This non-latching relay from Schneider Electric remains in a NO (normally on) position when current is passing through it. This makes it a good choice for keyboards and other devices that are pushbutton operated. The robust unit features an extended mechanical and electrical life for improved reliability – its polycarbonate enclosure offers protection against dust and moisture and make it better able to withstand everyday wear and tear. Solder terminals allow for a quick electrical connection that’s strong enough to perform in harsh industrial environments.
Features & Benefits
• Reliable silver-alloy contacts with good electrical conductibility for improved energy transfer
• Wide operating temperature range of -40°C to +85°C for use in a broad range of environments
• Maximises packing efficiency in a control panel with space-saving dimensions of 38.89 (L) x 35.72 (H) x 48.42mm (D)
Applications
• Medical devices
• Household appliances
• Telecommunication equipment
• Robotics
What are the most important factors to consider when choosing a relay?
There are several important factors to consider when choosing a relay. These include the coil voltage – if this is too high, it could damage the components. The coil power is also important and should match the power of the circuit you’re using it in.
