Description
| คุณสมบัติ | Value |
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | Panel Mount |
| Switching Current | 40A |
| Latching | No |
| Number of Poles | 2 |
| Terminal Type | Screw |
| Coil Resistance | 70Ω |
| Coil Power | 4W |
| Maximum Switching Voltage AC | 600V |
| Maximum Switching Voltage DC | 28V |
| Length | 79.2mm |
| Isolation Coil To Contact | 2.2kV ac |
| Depth | 63.5mm |
| Height | 58.67mm |
| Maximum Switching Power AC | 1-1/2 hp |
| Application | Power |
199 Series
The 199 series open type, heavy duty power relays offer high-capacity switching with high dielectric strength.
High-power contacts
Riveted construction
Blowout magnet option
RoHS compliant
