Description
| คุณสมบัติ | Value |
| Coil Voltage | 120V ac |
| Contact Configuration | 3PDT |
| Mounting Type | Plug In |
| Switching Current | 12A |
| Latching | No |
| Number of Poles | 3 |
| Terminal Type | Plug In |
| Coil Resistance | 1700Ω |
| Coil Power | 2W |
| Maximum Switching Voltage AC | 300V |
| Length | 40.9mm |
| Height | 36.6mm |
| Isolation Coil To Contact | 1.5kVrms |
| Depth | 50.3mm |
| Maximum Switching Power DC | 500mW |
| Application | Automotive |
750H Series Power Relays
750H series relays are hermetically sealed and are specially designed for use in hazardous locations.
Octal style mounting
12 A maximum switching current ideal for automation and control applications
DPDT & 3PDT contact configuration
Socket mount option
