Description
| คุณสมบัติ | Value |
| Coil Voltage | 24 V dc |
| Number of Poles | 3 |
| Contact Current Rating | 9 A |
| Power Rating | 5.5 kW |
| Normal State Configuration | 1NC + 1NO |
| Range | TeSys |
| Function | Reversing |
The Schneider Electric TeSys D series is a contactor which has a built in bidirectional peak limiting diode suppressor coil technology. It is used in applications like resistive load and motor control. The type of connection for power and control circuit is through lugs-ring terminal.
Signalling circuit frequency is 25 to 400 Hz
Ambient operating temperature is -40 to 60 °C
