Description
| คุณสมบัติ | Value |
| Number of Poles | 3P |
| Current Rating | 7A |
| Rated AC Voltage | 690V |
| Model Number | GV4L07N |
| Range | TeSys |
| Series | GV4L |
| Breaking Capacity at Maximum Voltage Rating | 50 kA |
| Circuit Breaker Type | MCB |
| Mounting Style | DIN Rail Mount |
| Width | 165mm |
| Length | 81mm |
| Depth | 155mm |
| Terminal Contact Type | Screw |
| Tripping Mechanism | Magnetic |
New TeSys GV4 is a compact and robust motor circuit breaker, up to 115 A with 100 kA breaking capacity, available with 3 kinds of protection: magnetic, electronic thermal magnetic, electronic thermal magnetic with advanced protections and alarming designed for demanding applications.TeSys GV4 is also equiped with patented Everlink power connections, and may be equiped with a wide range of accessories, mainly: auxiliaries (1 OF, 1SD, 1 coil MN or MX), rotary handle (direct, front extended or side) and advanced alarming and fault differentiation module.
b Magnetic GV4L: to be used with an overload relay or a drive
b Thermal magnetic GV4P: electronic protection with wide range setting, dual class (10 & 20)
b Multifunction motor protection GV4PEM: GV4P with adjustable advanced protections and possibility to have
a side module SDx for alarming and fault differentiation.
