Description
| คุณสมบัติ | Value |
| Number of Poles | 2P |
| Current Rating | 20A |
| Tripping Characteristics | Type B |
| Rated AC Voltage | 230 V, 400V |
| Rated DC Voltage | 60V |
| Series | 5SJ6 |
| Range | Sentron |
| Breaking Capacity at Maximum Voltage Rating | 6 kA |
| Circuit Breaker Type | MCB |
| Mounting Style | DIN Rail Mount |
| Width | 36mm |
| Length | 90mm |
| Depth | 76mm |
Series 5SJ6 MCBs – 6kA, B & C Characteristics
Line protective switches with quick plug in terminals
Mainly used to protect socket outlet and lighting circuits with rated currents from 10 to 63 A
DIN rail assembly
Touch protection to VBG4 / BGV A2
Rated voltage: 1P – 230/400Vac; 1P+N – 230Vac; 2P/3P+N/4P – 400Vac
Breaking capacity: 6kA
Double screwless outgoing terminal for rigid and flexible contuctors: – rigid: 1 to 4mm² – Flexible: 1 to 2.5mm²
If flexible conducts, no end sleeves necessary
Completely compatibility with all other 5SJ and 5SY miniature circuit breakers
Tool-free disconnection and manual removal
depth 70mm
Standards
EN 60898, VDE 0641 part of 11, IEC 60898
