Description
| คุณสมบัติ | Value |
| Power Rating | 0.25 kW |
| Phase | 1 |
| Supply Voltage | 230 V ac |
| Current Rating | 1.7 A |
| Output Frequency | 0 → 550Hz |
| For Use With | AC Motors |
| Series | SINAMICS V20 |
| IP Rating | IP20 |
| Field Bus Communication Type | USS/Modbus RTU |
| STO | No |
| Mounting Type | Side by Side Mount, Wall Mount |
| Overall Depth | 108mm |
| Overall Width | 68mm |
| Standards Met | CE, C-Tick (RCM), cULus, EN 60204-1, EN 61800-3, EN 61800-5-1, KCC |
| Overall Length | 142mm |
Siemens Single-Phase Inverter Drive, 230V AC, 0.25kW Power Rating – SINAMICS V20 Series – 6SL3210-5BB12-5UV1
Use this inverter drive from Siemens to convert AC (alternating current) power to DC (direct current) power. Thanks to its broad output frequency range of 0 to 550Hz, it’s suitable for both low-frequency and high-frequency applications, making it a versatile choice. For remote operation and ease of data analysis, you can connect it to a USS (universal serial interface) or Modbus remote terminal unit communication system. Inverter drives like this one are commonly used in commercial and industrial environments to regulate devices such as pumps and fans.
• Wide operating temperature range of -10°C to +60°C for use in demanding environments
• Advanced cooling design to prevent overheating
• ECO mode enables standby operation to reduce energy consumption
• Low power rating of 0.25kW for minimal energy consumption
• Control buttons on enclosure for simple configuration
How do I mount this inverter drive?
You can mount this inverter drive on a wall for easy access. Thanks to its compact dimensions of 142 (height) x 68 (width) x 107.8mm (depth), it’s also suitable for side-by-side mounting to maximise space on a control panel.
