Description
| คุณสมบัติ | Value |
| Coil Voltage | 240 V |
| Number of Poles | 3 |
| Contact Current Rating | 95 A |
| Power Rating | 25 kW |
| Normal State Configuration | 3NO |
| Range | TeSys |
The Schneider Electric TeSys D contactor, 3 poles (3NO), for motor control applications up to 95A/1000V AC-3 (45kW@400V). It provides a 240V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts, power connection by screw terminals and control by screw clamp terminals. Compact (85mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability
