Description
| คุณสมบัติ | Value |
| Coil Voltage | 110 V ac |
| Number of Poles | 3 |
| Contact Current Rating | 115 A |
| Power Rating | 55 kW |
| Normal State Configuration | 3NO |
| Contact Voltage Rating | 1 kV ac |
| Range | TeSys D |
| Series | LC1D |
| Number Of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1NO + 1NC |
| Terminal Type | Screw |
| Width | 120mm |
| Depth | 132mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +60°C |
| Length | 158mm |
Schneider Electric LC1D115F7 Contactor
The Schneider Electric LC1D115F7 model is a 3 pole contactor featuring a 110 V ac operating coil, with an AC-3 full load current rating of 115 A.
Features & Benefits
• Light weight of 2.5kg, so it’s easy to handle and won’t strain your equipment
• Built-in bidirectional peak limiting diode suppressor for coil protection
• Mechanical service life of 8,000,000 cycles for long-term performance
• Ingress protection rating of IP20 to withstand dust and objects larger than 12mm
Applications
• Squirrel cage motors
• Elevators and escalators
• Industrial mixers
Can I use this contactor in cold environments?
This contactor is designed to operate optimally within a temperature range of -5°C to +60°C so you can use it in both hot and cold environments.
