Description
| คุณสมบัติ | Value |
| Number of Poles | 2P |
| Current Rating | 6A |
| Tripping Characteristics | Type C |
| Series | 5SV6 |
| Range | SENTRON |
| Model Number | 016-7KP06 |
| Breaking Capacity at Maximum Voltage Rating | 1 A |
| Circuit Breaker Type | AFDD-MCB |
| Mounting Style | DIN Rail Mount |
The Siemens 5SV6 6A arc fault detection device (AFDD) is the first manufacturer in the IEC market to present the third generation of fire prevention products. The 5SV6 AFDD is the first device with integrated miniature circuit breaker (MCB) in just one modular width (instead of the previous 2mW). Additionally, it is the smallest of its kind worldwide.
Product is silicon and halogen free
Power loss for rated value of the current at AC in hot operating state per pole is 0.45W
Supply voltage at AC rated value is 230V and for testing equipment, it is kept to minimum at 195V
Supply voltage frequency is rated at value 50Hz
