Description
| คุณสมบัติ | Value |
| AC or DC Input Voltage | ac, dc |
| AC or DC Output Voltage | dc |
| Input Voltage | 85 → 275V ac |
| Output Voltage | 24V dc |
| Output Current | 20A |
| Power Rating | 480W |
| Number of Outputs | 1 |
| Electrical Phase | 1, 2 |
| Type | Switch Mode |
| Height | 125mm |
| Hazardous Area Certification | ATEX |
| Series | SITOP PSU8200 |
| Mounting Type | DIN Rail Mount |
| Width | 90mm |
| Output Voltage Adjustment Range | 24 → 28.8V |
| Depth | 125mm |
| Load Regulation | 0.3% |
| Ripple And Noise | 100mV Pk-Pk |
| Minimum Temperature | -25°C |
| Maximum Temperature | +70°C |
SITOP Modular Power Supply
The one, two and 3 phase SITOP modular units are the technology power supplies for demanding solutions. They offer maximum functionality for use in complex plants and machines. The wide-range input allows a connection to almost any electrical power system worldwide. The input ensures a high degree of safety even if there are large voltage fluctuations. They offer outstanding overload characteristics: Power boost delivers up to three-times the rated current for short periods of time. With extra power of 150%, loads with high power consumption can be connected without any problems. And if there is an overload, you can choose between constant current or automatic restart. The high efficiency keeps energy consumption and heat buildup in the control cabinet low, and the compact metal enclosure also saves space.
Features and Benefits
• Slim design
• Power boost with 3 times rated current for tripping protective devices
• Extra power with 1.5 times rated current for brief functional overload
• Selectable short circuit response between constant current and restart
• Symmetrical load distribution can be selected for parallel operation
• Operating state on 3 LEDs
• High efficiency up to 94%
• Temperature range: -25°C to 70°C
Product Application Information
To increase the 24 V availability, the SITOP smart power supplies can be combined with buffer, DC UPS, redundancy and selectivity modules.
Why use a DIN Rail power supply?
The flexibility of DIN Rail mounting systems enables quicker installation time as all devices are able to simply snap onto the metal rails. Power supplies can be easily organised on DIN Rails within enclosed wall boxes or in areas where there is limited space. Similar devices can be mounted next to each other reducing the amount of cabling required. Most power supplies are convection cooled so no cooling fans are needed.
DIN Rail AC to DC power supplies are widely used in many automation, instrumentation and industrial applications. They are used to power a wide variety of DC operated devices including sensors, motors, actuators, solenoids, relays and many more.
Points to consider when buying a DIN Rail power supply
DIN Rail size – There are three common types of DIN Rails. Top Hat, G section and C section. Most have a depth of 7.5 mm or 15 mm. It is wise to check that your power supply is compatible with your DIN Rail.
Protection types – It is important to choose a power supply that is protected against either short circuit, overload, over temperature or over voltage. Some power supplies also offer a hiccup mode which will allow the PSU to resume operation once the fault is cleared.
Fixed or adjustable output voltage or current – In test systems it is often convenient to have adjustable DC voltage however in other applications a fixed DC supply may be essential.
Cabling and wiring – The input/output lines to and from the power supply should be as short as possible with a large cross sectional area to help minimise noise and heat.
Efficiency – Choose a power supply that has a high efficiency to minimise the amount of power dissipation, especially if the system relies on convection cooling.
Input voltage range – If the DIN Rail power supply you are buying is to be used in Europe and North America as well as the UK then a universal AC input range of 80 V ac to 264 V ac is required.
Standards – If the power supply is to be used in the USA for controlling electric motors then it will need to comply with Standard UL508, the safety standard for industrial control equipment.
Approvals
- CE
- cULus
- ATEX
- IECEx
- SEMI F47
- GL
- ABS
Approvals
CE, cULus, ATEX, IECEx, SEMI F47, GL, ABS
Siemens 6EP1336-3BA10 Power Supply, 24 V, 20 A, 480 W
Safely power your PLC (programmable logic controller) with this switch-mode power supply unit (PSU) from Siemens. Its broad input voltage range of 85 to 275V AC or 88 to 350V DC makes it a versatile option that’s suitable for use with many electrical setups. To save on space, this device has compact dimensions of 125 (height) x 90 (width) x 125mm (depth). You can install it onto a DIN rail using its snap-in mechanism for simple, tool-free installation. Components like this one are commonly used with industrial servers and computer systems.
• Wide operating temperature range of -25°C to +70°C for use in demanding environments
• Adjustable output voltage range of 24 to 28.8V DC for versatility
• IP20 (ingress protection) rating means it’s touch-proof and protected against objects larger than 12mm in size
How do I monitor the status of this PSU?
You can easily monitor the status of this PSU using its three integrated LED indicators. A green light indicates that the system is operating normally, while a yellow light and a red light indicate overloads or latching shutdown respectively.
