Description
| คุณสมบัติ | Value |
| Power Rating | 0.12 kW |
| Phase | 1 |
| Supply Voltage | 230 V ac |
| Current Rating | 900 mA |
| Output Frequency | 0 → 550Hz |
| For Use With | AC Motors |
| Series | SINAMICS V20 |
| IP Rating | IP20 |
| Field Bus Communication Type | USS/Modbus RTU |
| STO | No |
| Mounting Type | Side by Side Mount, Wall Mount |
| Overall Length | 68mm |
| Overall Width | 107.8mm |
| Standards Met | CE, C-Tick (RCM), cULus, EN 60204-1, EN 61800-3, EN 61800-5-1, KCC |
| Overall Depth | 142mm |
Sinamics V20 – Single Phase Input with filter
SINAMICS V20 is a cost-effective, reliable and easy-to-use inverter for basic applications.
V20 Inverter Drive
Single phase input
With filter
USS and MODBUS RTU at terminals
Wide voltage range
ECO mode for V/f and V²/f
Advanced cooling design
Parameter loading without power supply
Push-through or wall mounting
Applications:
Centrifugal pumps
Radial/axial fans
Compressors
Conveyors
Single drives in the process
Siemens Sinamics V20 Range
